Technical characteristics

1) Display mode: LCD digital display

2) Measurement method: oscillometric measurement method

3) Pressure measurement range: 0～300mmHg (0～40kPa)

4) Pulse rate measurement range: 40~200 times/minute

5) Accuracy: Pressure: within ±3mmHg (±0.4kPa) Pulse rate: ±5%

6) Operating mode classification: continuous operation

7) Electrical safety classification: Internal power supply equipment, Class II equipment, Type B applied part.

8) Liquid ingress protection category: Ordinary equipment IPXO

9) Applicable range of cuff: 22～49CM

10) Dimensions: 128×99×58 mm

11) Display size: 50X80mm

12) Net weight: about 220g (clear battery)

13) Applicable power supply: DC 6V 500MA or 4 No. 7 dry batteries

14) Battery consumption: The capacity of 4 No. 7 high-performance dry batteries is measured about 200 times (under the current 23°C, pressurized to 190mmHg (25.3kPa) each time).

15) Working temperature and humidity: +5℃～+40℃, 15%RH～80%RH

16) Working air pressure: 80kPa～105kPa

17) Transportation and storage temperature and humidity: -20℃～+55℃, 15%RH～80%RH.

18) Color box size: 160×108×80MM

19) 50 units in outer box Specifications: 55×42.5×34CM
